DVR 8CH Avtect DGD 1308

Detail DVR 8CH Avtect DGD 1308

2 MP DVR Avtech DGD1308 8 Channel
Resmi Avtech Indonesia

Video System NTSC / PAL (auto detection)
Video Compression Format H.264
Video Signal Analog HD / TVI / CVI / 960H
Video Input 4 channels (Composite video signal 1 Vp-p 75Ω BNC)
Video Output BNC YES (Main Monitor / Call Monitor selectable)
VGA YES
HDMI YES
Video Resolution 1080P / 720P / QHD / 960H / Frame / Field / CIF
 Record & Backup
Max. Recording Rate 1920 x 1080 @ 60 IPS / 50 IPS
1280 x 720 @ 120 IPS / 100 IPS
Recording Mode Manual / Timer / Motion / Remote
Pre-alarm Recording YES
Playback Channel 4CH
Quick Search Time / Motion search mode
Backup Device USB 2.0 drive / Network
Regular Backup YES
 Audio
Audio Input 1 audio input
Audio Output 1 audio output (Mono)
 General
Hard Disk Storage 10TB SATA HDD x 1
SATA Interface YES
Image Quality Setting SUPER BEST / BEST / HIGH / NORMAL
USB Mouse Control YES
Motion Detection Area 16 × 12 grids per channel
Motion Detection Sensitivity 3 adjustable parameters for accurate detection
Event Notification Push Status / FTP / E-Mail
Picture Zoom 2X digital zoom
IR Remote Control YES (IR receiver built-in)
Key Lock (Password Protection) YES
User Level 4 user levels for different access privilege
Video Loss Detection YES
Camera Title Supports up to 25 letters
Video Adjustable Hue / Saturation / Contrast / Brightness
Date Display Format YY/MM/DD, DD/MM/YY & MM/DD/YY
Daylight Saving YES
Power Source (±10%) DC12V / 2A
Operating Temperature 10ºC ~ 40ºC (50ºF ~104ºF)
Operating Humidity 10% ~ 85%
Dimensions (±10%)** 260(L) x 48(H) x 235.7(D)

Gambar produk
