Features Connectable to Turbo HD/HDCVI/AHD/CVBS signal input Long distance transmission over UTP and coaxial cable One-key enable H.264+ compression to improve encoding efficiency by up to 50% and reduce data storage costs Supports real-time 1080p lite and when enabled, the image effect is similar with 1080p HDMI/VGA output at up to 1920 1080 resolution One SATA interface (up to 6 TB capacity per HDD) 4ch synchronous playback Smart search for efficient playback
Specifications Audio Input : 1-ch Video Compression : H.264,H.264+ Analog Video Input : 4-ch P Video Input : 1-ch Up to 960P resolution Video Input Interface : BNC (1.0 Vp-p, 75) Audio Compression : G.711u Audio Input Interface : RCA (2.0 Vp-p, 1 k) Two-way Audio : 1-ch RCA(2.0Vp-p, 1k) HDMI/VGA Output : 1920 1080 / 60 Hz,1280 1024 / 60 Hz, 1280 720 / 60 Hz, 1024 768 / 60 Hz Stream Type : Video/Video&Audio Dual Stream : Support Synchronous Playback : 4-ch Interface Type : 1 SATA Interface Capacity : Up to 6 TB capacity for each disk
Produk original OEM hikvision teknologi. Terimakasih
