Dlink DGS-1100-24 24-Port Easy Smart Gigabit Rackmount

Detail Dlink DGS-1100-24 24-Port Easy Smart Gigabit Rackmount

DLINK DGS-1100-24v2


Overview :
● 24 x 10/100/1000BASE-T ports
● Fanless design for silent operation
● Bandwidth Control ensures latency-sensitive traffic always gets the bandwidth it needs
● Quality of Service further prioritizes latency-sensitive traffic, ensuring timely delivery
● Segregate different types of traffic, such as surveillance or voice, with VLANs to heighten security
● IGMP Snooping sends multicast traffic only where it needs to go, significantly cutting down network traffic
● Innovative energy saving features are good for your budget, as well as the environment
● Get up and going quickly with streamlined first-time setup and ongoing management

Specifications :
10/100/1000BASE-T ports : 24
Auto MDI/MDIX : Yes
Switch Capacity : 48 Gbps
Max. Packet Forwarding Rate : 35.71 Mpps
Jumbo Frame : 9216 bytes
Loopback Detection (LBD) : Yes
IGMP Snooping : Yes
802.1Q VLAN : Yes
Port-based VLAN : Yes
Voice VLAN : Yes
Auto Surveillance VLAN : Yes
Asymmetric VLAN : Yes
Store-and-Forwarding : Yes
Operation Temperature : -5-50°C
Power Input : AC: 100-240V
FAN : Fanless
Comply with RoHS 6 : Yes
Energy Efficiency Ethernet (EEE) : Yes
802.3x Flow Control : Yes
802.1D Spanning Tree (STP) : Yes
802.1w Rapid Spanning Tree (RSTP) : Yes
802.1AX Link Aggregation : Yes
802.3ad Link Aggregation : Yes
Port Mirroring : Yes
Class of Service (CoS) : Yes
Rate Limiting : Yes
Queue Handling : Yes
Strict Priority Queue (SPQ) : Yes
Weighted Round Robin (WRR) : Yes
Port-based Bandwidth Control : Yes
SSL : Yes
Broadcast/Multicast/Unicast Storm Control : Yes
Traffic Segmentation : Yes
D-Link Safeguard Engine : Yes
DoS Attack Prevention : Yes
Cable Diagnostics : Yes
Web-based GUI : Yes
SNMP : Yes
D-Link Discover Protocol (DDP) : Yes (v0.25)
D-Link Network Assistant : Yes
