Detail Dimmer PWM 70A DC Motor Speed Controller 12V 24V 36V (1506)
PWM DC motor motor speed controller forward rotation reverse switch bidirectional controller 12V24V36V
Product parameter
Product name: Time position 70A108S
Input voltage: DC10-60V
Output voltage: Linear under load
Input current: It is required to be larger than the working current of the motor.
Output current: The load size determines the continuous current: within 70A
Power conversion: (power etc. and voltage * current) Quiescent current: 0.01ma
Speed regulation type: current regulation
Speed regulation method: linear potentiometer 270 degrees
speed regulation range: 0-100%
current limit protection: 80A
Body size: 150mm*85mm*45mm
Product net weight: 550g
