Detail Dimmer PWM 40A DC Brush Motor Speed Controller 12V 24V 36V 48V

Input voltage: DC10-50V Output voltage: linear under load

Dimmer PWM 40A DC Brush Motor Speed Controller 12V 24V 36V 48V

Output limit current: 40A (use 20A for a long time, pay attention to keep the module smooth and heat dissipation conditions)
Ultimate power: 2000W

Speed regulation type: current regulation speed regulation method: potentiometer (linear)

Speed regulation duty cycle range: 0-100% control frequency: 25KHZ

Wiring type: Barrier terminal, knob wire length: 20CM

Product net weight: 245 grams

Motherboard installation size: length * width 100MM*76MM*28MM potentiometer installation opening: 7MM
