Digital Signal Processor DSP ZEVOX ZP 8.6 PRO-MKII By VOX Research

Detail Digital Signal Processor DSP ZEVOX ZP 8.6 PRO-MKII By VOX Research

Digital Signal Processor DSP ZEVOX ZP 8.6 PRO-MKII By VOX Research

NB :
(Harga Nett Chat Penjual)

Specifications:
• Processor 8 CH with Built-In 6 CH Amplifier, 4+2 In 8 Out
• 31 Band Independent Parametric / Graphic EQ
• Active Range : ≥110dB
• S/N Ratio : ≥100dB
• T.H.D : ≤0.05%
• Freq. Response : 20Hz~20KHz
• Input Impedance : Low Level Input : 20KΩ, High level input : 240Ω
• Low level output Impedance : 100Ω
• Power Output (4 Ohm) : RMS 25W X4 + 90W X2, Peak Power 60W X4 + 230W X2
• Signal Input & output range : RCA Input: 6Vpp ; High level : 26Vpp; RCA Output 9Vpp ; Amplifier : 26Vpp
• Lossless Audio Player (USB) for FLAC, WAV, AIFF, WMA, APE, M4A, MKA, AU, MPC, ALAC, TTA, OGG, AAC, MP3
• Temperature : -20 ~ 70°C
• Supply Voltage : DC 9V ~ 16V
• Sampling Rate : 48KHz/24Bit
• Turn-on REM output : +12 V starting voltage output (0.2A)
• Power Consumption : ≤0.1W
• Bluetooth Audio Player
• Android & iOS Audio Player App
• Android & iOS App for DSP Setup & Tuning
• OEM Plug & Play Cable (Optional)
• Dimensions : 330 x 160 x 51 mm

Gambar produk
