Detail DHT22 DHT-22 AM2302 Humidity & Temperature With Case Wired Sensor Suhu DHT22

Hi #RekanEasyWare ...
EasyWare Part#: EP000601

Specification :
- AM2302 (Wired DHT22) Temperature and Humidity Sensor operating voltage 3 to 5 volts DC.
- Its maximum current consumption is approximately 2.5mA during a data request.
- The user is able to get new data once every 2 seconds.
- it provides output as a digital single bus.
- Its air humidity measuring range is 0 to 100%.
- 0 to 80 degrees centigrade is its temperature measuring range.
- Its air humidity tolerance range is 2 to 5%.
- Its temperature tolerance is 0.5%.
- There is a 5.1K resistor inside this sensor. This resistor is called a pull-up resistor. And it is connected to the VCC and Data.
- 0.5 Hz is its sampling rate. And this sampling rate is after 2 sec.
- Its cable length is approximately 25cm.
- It has +- 0.5-degree centigrade accuracy in temperature readings.
- it has excellent long-term stability calibration
- Its size is 59 x 27 x13mm.

Packaging:
- 1x AM2302 DHT22 Temperature Humidity Sensor With Case wired Board
