DH48S-1Z Digital Timer Relay On Delay 8 Pins Reset/Pause Function 220v

Elektronik > Kelistrikan > Saklar > DH48S-1Z Digital Timer Relay On Delay 8 Pins Reset/Pause Function 220v
Tersedia
Periksa harganya...
Lihat tempat menjual
Toko:GoodthingsinsidedogLihat semua produk Elektronik oleh Goodthingsinsidedog
  • Pengiriman Ekspres
  • Barang yang diperiksa
  • Bayar di tempat berlaku
  • Kualitas, Prestise
  • Pengembalian produk
  • Dukung pembuatan faktur
DeskripsiSpesifikasi

Detail DH48S-1Z Digital Timer Relay On Delay 8 Pins Reset/Pause Function 220v

Technology Specification:
Power Source:85-110% Rated Voltage
AC: 220V
Dealy Range: 0.01s~99.99s  1s~99m99s  1m~99h99m
Repeat accuracy: <0.3%±0.5sec
Contact Capacity: AC220V 5A
Mechanical life: »10000000
Electrical Life»100000
Operating ambient temperature: -10℃-50℃
Power consumption: ≤5W
Altitude: <2000m
Dimension: 48*48mm
Hole Size: 45*45mm
