Type : ATX12V V2.4 Product Dimensions : 150×140×86mm (W x L x H) 80PLUS Certifications : 230V EU White Fan Size : 120mm Fan Bearing : Hypro Bearing Topology : Active PFC+Double tube forward Capacitors : Taiwan bulk capacitor Power Good Signal : 100-500ms Hold Up Time : ≥10ms(75% Load) Efficiency : ≥85% Under Typical Load(50% Loading) Protection : OPP/OVP/SCP/UVP Operation Temperature : 0-30°C Regulatory : CB/CCC/CE/UKCA/EAC/RCM/BIS Erp Regulation : ErP 2010 MTBF : 100,000 Hours
Main Power Connector 24 (20+4)Pin x1 EPS 12V Connector 8 (4+4)Pin x2 PCI-E (6+2)Pin x2 - 2Cable SATA x3 + 4Pin Peripheral x1 - 2Cable
