Deepcool Castle 240 EX A-RGB I 360 EX A-RGB - AIO Liquid CPU Cooler

Detail Deepcool Castle 240 EX A-RGB I 360 EX A-RGB - AIO Liquid CPU Cooler

Ada 4 Varians :

1. Castle 240 EX A-RGB Black
2. Castle 240 EX A-RGB White
3. Castle 360 EX A-RGB Black
4. Castle 360 EX A-RGB White

Application For
Socket Intel LGA
2066/2011-v3/2011/1200/1151/1150/1155/1366AMD
Socket AMD
TRX4/TR4/AM4/AM3+/AM3/AM2+/AM2/FM2+/FM2/FM1

Technical Spec Castle 240 EX A-RGB Liquid Anti Leak
Radiator Dimensions 282×120×27 mm
Radiator Material Aluminum
Tube length 380 mm
Pump Dimensions 86 ×75×71 mm
Pump Speed 2550 RPM±10%
Pump Noise 17.8 dB(A)
Pump Connector 3-pin
Pump Rated Voltage 12 VDC
Pump Rated Current 0.2 A
Pump Power Consumption 2.4 W
Fan Dimensions 120×120×25 mm
Fan Speed 500~1800 RPM±10%
Fan Airflow 69.34 CFM
Fan Air Pressure 2.42 mmAq
Fan Noise ≤30 dB(A)
Fan Connector 4-pin PWM
Bearing Type Hydro Bearing
Fan Rated Voltage 12 VDC
Fan Rated Current 0.17 A
Fan Power Consumption 2.04 W
Led Type Addressable RGB LED
Led Connector 3-pin(+5V-D-G)
Led Rated Voltage 5 VDC
Led Power Consumption 2.25 W（PUMP）/ 4.4 W（FAN×2）

Technical Spec Castle 360 EX A-RGB Liquid Anti Leak
Radiator Dimensions : 402×120×27 mm
Radiator Material : Aluminum
Tube length : 465 mm
Pump Dimensions : 86×75×71 mm
Pump Speed : 2550 RPM±10%
Pump Noise : 17.8 dB(A)
Pump Connector : 3-pi
Pump Rated Voltage : 12 VDC
Pump Rated Current : 0.2A
Pump Power Consumption : 2.4 W
Fan Dimensions : 120×120×27 mm
Fan Speed : 500~1800 RPM±10%
Fan Airflow : 60.6 CFM
Fan Air Pressure : 1.73 mmAq
Fan Noise : ≤35 dB(A)
Fan Connector : 4-pin PWM
Bearing Type : Hydro Bearing
Fan Rated Voltage : 12 VDC
Fan Rated Current : 0.12 A
Fan Power Consumption : 1.44 W
Led Type : Addressable RGB LED
Led Connector : 3-pin(+5V-D-G)
Led Rated Voltage : 5 VDC
Led Power Consumption : 2.25 W（PUMP）/ 11.1 W(FAN×3)

Gambar produk
