Detail DC to DC Adjustable 9A 300W Step down Buck Converter 5-40V to 1.2-35V Power Supply module

Hi #RekanEasyWare ...
EasyWare Part#: EP000663

SPESIFIKASI :
- Module properties: Non-isolated step-down constant current, constant voltage module (CC CV) charging module
- Input voltage: DC 7-32V
- Output voltage: (1) DC 0.8-28V continuously adjustable. (2) Fixed output:Choose between 0.8v-28v
- Output Current: 8A (when power tube's temperature exceeds 65 degrees, please add cooling fan)
- Constant current range: 0.2-8A ( adjustable )
- Turn lamp current: Constant current value * ( 0.1 ) , turn the lamp current and constant value linkage, such as constant current value is 3A, turn the lamp current is set to a constant current is 0.1 times (0.1 * 3A = 0.3A).
- Lowest pressure: 1V
- Output Power: Maximum power is about 300W
- Conversion efficiency: Up to about 95%
- Operating frequency: 300KHZ
- Output ripple: 20M bandwidth
- Input 24V output 12V 5A ripple around 50mV (Excluding noise)
- Output short circuit protection : Yes, constant current
- Input reverse polarity protection: None
- Output prevent backflow: None
- Wiring: Terminal
- No-load current: Typical 20mA (24V switch 12V)
- Load regulation: ± 1% ( constant )
- Voltage regulation: ± 1%
- Dynamic response speed: 5% 200uS
- Potentiometer adjustment direction: clockwise (increase) , counterclockwise (decrease), the potentiometer(CV) closed to the input voltage is used to regulate voltage, the potentiometer(CC) closed to output voltage is used to regulate current (CC)
- Operating temperature: Industrial grade (-40 °C to +85 °C) ( please note the actual use of the power tube temperature , high temperature heat strengthened)
- Indicator: dual color indicator, charging indicator light is red, the green light means fully charged ( No load is green )

KELENGKAPAN :
- 1pcs DC/CC Adjustable 0.2- 9A 300W Step Down Buck Converter 5-40V To 1.2-35V Power Supply Module LED Driver for Arduino

Gambar produk

DC to DC Adjustable 9A 300W Step down Buck Converter 5-40V to 1.2-35V Power Supply module
DC to DC Adjustable 9A 300W Step down Buck Converter 5-40V to 1.2-35V Power Supply module
DC to DC Adjustable 9A 300W Step down Buck Converter 5-40V to 1.2-35V Power Supply module
