Dc-Dc Papan Buck Modul Daya Charger Mobil 9v/12v/24v Ke 5v 3a Usb

Detail Dc-Dc Papan Buck Modul Daya Charger Mobil 9v/12v/24v Ke 5v 3a Usb

DC-DC 9V/12V/24V to 5V Step Down Charger Power Module 3A Output USB Car Charging Regulator Buck Voltage Board
Descriptions:

A switching step-down DC-DC converter module;


Fixed switching frequency 150KHz, the chip has excellent linearity adjustment and load regulation, fixed output 5V.


The chip integrates reliability modules such as overcurrent protection, overtemperature protection, and short circuit shutdown.


Specifications:
Input: 5V-36V
Output: 5V/3A
Conversion Efficiency: 96%
Switching Frequency: 150KHz
Working Temperature: -40°C-+85°C
Load Capacity: Maximum Output 3A, Long-Term Work 2A
Product Size: 38 X 16 X 5mm/1.5 X 0.63 X 0.2"
Packing Weight: 6g
Scope of Application: USB 5V powered devices such as mobile power, mobile phones, and tablets

Notes:
1. Due to the different monitor and light effect, the actual color of the item might be slightly different from the color showed on the pictures. Thank you!
2. Please allow 1-3mm measuring deviation due to manual measurement.
