DAHUA SWITCH POE 4 PORT + 2 PORT UPLINK DH-PFS3006-4ET-36 ORIGINAL

Detail DAHUA SWITCH POE 4 PORT + 2 PORT UPLINK DH-PFS3006-4ET-36 ORIGINAL

Ready Stok
Garansi Resmi Dahua

DH-PFS3006-4ET-36
6-Port Fast Ethernet Switch with 4-Port PoE
▪︎Support four 10/100M PoE power supply ports, and two 10/100M
uplink ports
▪︎Support 802.3af and 802.3at standards
▪︎OperatingTemperature: -10°C to +55°C
▪︎Support 250 m long distance PoE tansmission
▪︎Support PoE watchdog

▪︎Power Consumption Idling: 0.5W
Full load: 36W

PoE
▪︎PoE Budget: Port1-4 ≤30W, whole ▪︎PoE budget: ≤36W
▪︎PoE Standard: IEEE802.3af, IEEE802.3at
▪︎PoE Pin Assignment PoE: 1, 2, 4, 5(V+), 3, 6, 7, 8(V-)

Performance
▪︎Switching Capacity: 1.2 Gbps
▪︎Packet Forwarding Rate: 0.89 Mpps
▪︎MAC Table Size: 2 K
▪︎Jumbo Frame: 2048 byte
▪︎Communication Standard: IEEE 802.3, IEEE 802.3u, IEEE 802.3X

Performance
▪︎ESD Air discharge: 8kV
Contact discharge: 6kV
▪︎Thunderproof Common mode: 6kV
Differential mode: 4kV
