D-LINK DGS-1100-16 V2 16-Port Gigabit Smart Managed Switch

Detail D-LINK DGS-1100-16 V2 16-Port Gigabit Smart Managed Switch

D-LINK DGS-1100-16 V2 16-Port Gigabit Smart Managed Switch

16 x 10/100/1000BASE-T ports
Fanless design for silent operation
Bandwidth Control ensures latency-sensitive traffic always gets the bandwidth it needs
Quality of Service further prioritizes latency-sensitive traffic, ensuring timely delivery
Segregate different types of traffic, such as surveillance or voice, with VLANs to heighten security
IGMP Snooping sends multicast traffic only where it needs to go, significantly cutting down network traffic
Innovative energy saving features are good for your budget, as well as the environment
Get up and going quickly with streamlined first-time setup and ongoing management

Specifications
10/100/1000BASE-T ports 16
Auto MDI/MDIX Yes
Switch Capacity 32 Gbps
Max. Packet Forwarding Rate 23.81Mpps
Store-and-Forwarding Yes
Dimension 280x 180x 44mm
Weight 1.27 Kg
Operation Temperature -5-50°C
Power Input AC: 100-240V
FAN Fanless
Comply with RoHS 6 Yes
Energy Efficiency Ethernet (EEE) Yes
802.3x Flow Control Yes
802.1D Spanning Tree (STP) Yes
802.1w Rapid Spanning Tree (RSTP) Yes
802.1AX Link Aggregation Yes
802.3ad Link Aggregation Yes
Port Mirroring Yes
Jumbo Frame 9216 bytes
Loopback Detection (LBD) Yes
IGMP Snooping Yes
802.1Q VLAN Yes
Port-based VLAN Yes
Voice VLAN Yes
Auto Surveillance VLAN Yes
Asymmetric VLAN Yes
Class of Service (CoS) Yes
Rate Limiting Yes
Queue Handling Yes
Strict Priority Queue (SPQ) Yes
Weighted Round Robin (WRR) Yes
SSL Yes
Broadcast/Multicast/Unicast Storm Control Yes
Traffic Segmentation Yes
D-Link Safeguard Engine Yes
DoS Attack Prevention Yes
Port-based Bandwidth Control Yes
Cable Diagnostics Yes
Web-based GUI Yes
SNMP Yes
D-Link Discover Protocol (DDP) Yes (v0.25)
D-Link Network Assistant Yes
