DLink DGS-1008C Switch 8 Port Gigabit DGS-1008A 10/100/1000Mbps N1

Detail DLink DGS-1008C Switch 8 Port Gigabit DGS-1008A 10/100/1000Mbps N1

Features
Connectivity
Eight Gigabit Ethernet LAN ports for high-speed wired connections
Cable Diagnostics Function notifies users of cable conditions through product LEDs
Green Ethernet Features
Reduces power to a port when no link is detected
Adjust power to a port by detecting the length of the connected Ethernet cable

Technical Specifications
General
Device Interfaces
Eight 10/100/1000 Gigabit LAN ports
Functionality
Advanced Features
Green Ethernet
10 Gbps switching fabric
Auto MDI/MDIX crossover for all ports
Secure store-and-forward switching scheme
Full/half-duplex for Ethernet/Fast Ethernet speeds
IEEE 802.3x Flow Control
Supports 9,216 Byte Jumbo Frames
Supports IEEE 802.1p QoS (4 Queues, Strict Mode)
Supports Cable Diagnostics Function
Standards
IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
IEEE 802.3ab 1000BASE-T Gigabit Ethernet
ANSI/IEEE 802.3 NWay auto-negotiation
IEEE 802.3x Flow Control
IEEE 802.3az Energy-Efficient Ethernet (EEE)
Protocol
CSMA/CD
Data Transfer Rates
Ethernet:
10 Mbps (half duplex)
20 Mbps (full duplex)
Fast Ethernet:
100 Mbps (half duplex)
200 Mbps (full duplex)
Gigabit Ethernet:
2000 Mbps (full duplex)
Transmission Method
Store-and-forward
MAC Address Table
2 K
MAC Address Learning
Automatic Update
Packet Filtering/Forwarding Rates
Ethernet: 14,880 pps per port
Fast Ethernet: 148,800 pps per port
Gigabit Ethernet: 1,488,000 pps per port
RAM Buffer
128 KB per device
Physical
LED Indicators
Per port: Link/Activity/Speed
Per device: Power
Media Interface Exchange
Auto MDI/MDIX adjustment for all ports-
Dimensions
111 x 75 x 30 mm (4.4 x 3.0 x 1.2 inches)
Weight
330 grams
