D-Link DES-1005C Switch 5 Port 10/100 Mbps

Detail D-Link DES-1005C Switch 5 Port 10/100 Mbps

Device Interfaces
Five 10/100 Mbps LAN ports

Standards
IEEE 802.3 10BASE-T
IEEE 802.3u 100BASE-TX
IEEE 802.3x Flow Control
IEEE 802.3az Energy-Efficient Ethernet (EEE)

Switching Capacity
1.6 Gbps switching fabric

Advanced Features
Auto MDI/MDIX crossover for all ports
Secure store-and-forward switching scheme
Full/half-duplex for Ethernet/Fast Ethernet speeds
Supports 2,048 byte jumbo frames
Back pressure at half-duplex operation
Wire-speed reception and transmission
Store and-Forward switching method
Auto-negotiation for each port
EEE compliant IEEE 802.3 10BASE-T
IEEE 802.3u 100BASE-TX
IEEE 802.3az EEE
IEEE 802.3x flow control

Data Transfer Rates
Ethernet:
10 Mbps (half duplex)
20 Mbps (full duplex)
Fast Ethernet:
100 Mbps (half duplex)
200 Mbps (full duplex)

Transmission Method
Store-and-forward

MAC Address Table Size
2,000

Packet Filtering/Forwarding Rates
Ethernet: 14,880 pps per port
Fast Ethernet: 148,800 pps per port

RAM Buffer
96 KB per device

Physical Parameters
LED Indicators
Per port: Link/Activity/Speed
Per device: Power

Media Interface Exchange
Auto MDI/MDIX adjustment for all ports

Dimensions
131 x 54 x 21 mm

Weight
74.8 grams

Power
DC 5 V / 0.55 A
DC jack: Located on side

Power Consumption
Power On (Standby): 0.55 watts
Maximum: 1.55 watts

Temperature
Operating: 0 to 40C
Storage: -40 to 70C

Humidity
Operating: 10% to 90% (Non-condensing)
Storage: 5% to 95% (Non-condensing)

MTBF
1 579
