Corsair HX750 750Watt 80 Plus Platinum Certified Fully Modular

Detail Corsair HX750 750Watt 80 Plus Platinum Certified Fully Modular

CORSAIR HX Series Fully Modular Ultra-Low Noise Power Supplies deliver exceptional 80 PLUS Platinum efficient power with low-noise fluid dynamic bearing fan cooling. With dual EPS12V cables and four PCIe 8-pin power connectors, HX PSUs have all the connections needed to power today’s most demanding PC upgrades. Japanese 105°C-rated capacitors deliver long life and reliability, backed by a ten-year warranty. Wake your computer faster and consume less power with Modern Standby sleep mode. Zero RPM mode ensures near-silent operation at low and medium loads. Fully modular cabling makes PC builds easy, as you need only connect the required cables. Turn to the HX Series for platinum power that will last.

SPECIFICATION:
Part No. CP-9020212/75-004200
AC Input 100Va.c.-240Va.c
Input Current 10A-5A
Frequency 47~63Hz
Max Load Max Output
+3.3V 25A 150W
+5V 25A
+12V 62.5A 750W
-12V 0.3A 3.6W
+5Vsb 3A 15W
Total Power 750W
AC Input Rating


QTY DESCRIPTION Total
Connectors Connector
Spacing Total Cable LENGTH Cable type With cap
1 ATX CABLE 24-PIN
(24) 1 610mm ± 10mm SLEEVE NO
2 EPS/ATX12V CABLE
8-PIN (4+4) 2 650mm ± 10mm FLAT NO
2 PCIe CABLE 8-PIN
(6+2) 4 600mm, 150mm 750mm ± 10mm FLAT NO
2 SATA CABLE (3 SATA
- Right Angle) 6 520mm,
115mm,
115mm 750mm ± 10mm FLAT NO
1 SATA CABLE (4 SATA
- Right Angle) 4 505mm,
115mm,
115mm,
115mm 850mm ± 10mm FLAT NO
1 PATA CABLE (4-PIN) 4 450mm,
100mm,
100mm,
100mm 750mm ± 10mm FLAT NO

Gambar produk
