Cooler Master Power Supply V650 GOLD - V2 [MPY-650V-AFBAG-EU]

Detail Cooler Master Power Supply V650 GOLD - V2 [MPY-650V-AFBAG-EU]

Spesifikasi :
MODEL MPY-650V-AFBAG
ATX VERSION ATX 12V V2.52
PFC Active PFC
INPUT VOLTAGE 100-240V
INPUT CURRENT 9-4.5A
INPUT FREQUENCY 50-60Hz
DIMENSIONS (L X W X H) 160 x 150 x 86 mm
FAN SIZE 135mm
FAN BEARING FDB
FAN SPEED 1500 RPM
NOISE LEVEL @ 20% 0 dBA
NOISE LEVEL @ 50% 18.3 dBA
NOISE LEVEL @ 100% 32.1 dBA
EFFICIENCY 90% @ Typical Load
80 PLUS RATING 80 PLUS Gold
ERP 2014 LOT 3 Yes
OPERATING TEMPERATURE 0-50°C
POWER GOOD SIGNAL 100-500ms
HOLD UP TIME 17ms
MTBF >100,000 Hours
PROTECTIONS OVP, OPP, SCP, OCP, UVP, OTP
REGULATORY CCC, CE, TUV-RH, RCM, EAC, cTUVus, FCC, BSMI, KC, CB
ATX 24-PIN CONNECTORS 1
EPS 4+4 PIN CONNECTORS 1
EPS 8 PIN CONNECTOR 1
SATA CONNECTORS 8
PERIPHERAL 4-PIN CONNECTORS 4
FDD CABLE 4-PIN CONNECTORS 1
PCI-E 6+2 PIN CONNECTORS 4
SERIE V Gold Series
80 PLUS Gold
MODULAR Full Modular
WATTAGE 500 to 750W

Gambar produk
