Cooler Master MasterBox CM694 TG [MCB-CM694-KG5N-S00]

Detail Cooler Master MasterBox CM694 TG [MCB-CM694-KG5N-S00]

Specifications :
MODEL NUMBER MCB-CM694-KN5N-S00 (Steel), MCB-CM694-KG5N-S00 (TG)
SERIES MasterBox Series
SIZE Mid Tower
AVAILABLE COLOR(S) Black
MATERIALS Steel, Plastic, Tempered Glass, Mesh
DIMENSIONS (LXWXH) Steel: 493mm x 220mm x 506mm (incl. Protrusions), Steel: 482mm x 220mm x 477mm (excl. Protrusions), TG: 493mm x 224mm x 506mm (incl. Protrusions), TG: 482mm x 224mm x 477mm (excl. Protrusions)
MOTHERBOARD SUPPORT Mini ITX, Micro ATX, ATX, E-ATX
EXPANSION SLOTS 7
5.25" DRIVE BAYS 2
2.5" / 3.5" DRIVE BAYS (COMBO) 6 (3x drive cages)
2.5" DRIVE BAYS 8 (2 + 6 combo)
I/O PANEL 2x USB 3.0 Type A, 1x USB 3.1 Type-C, 1x 3.5mm Headset Jack (Audio+Mic)
PRE-INSTALLED FANS - FRONT 2x 120mm Fan (1200 RPM ± 200 RPM, 3 pin connector)
PRE-INSTALLED FANS - REAR 1x 120mm fan (1200 RPM ± 200 RPM, 3 pin connector)
FAN SUPPORT - FRONT 3x 120mm / 2x 140mm (wo/ODD), 2x 120mm / 2x 140mm (w/ODD)
FAN SUPPORT - TOP 3x 120mm, 2x 140mm
FAN SUPPORT - REAR 1x 120mm
RADIATOR SUPPORT - FRONT 120mm*, 140mm*, 240mm*, 280mm**, 360mm** (*remove 2 out of 3 drive cages) (**remove 2 out of 3 drive cages & ODD cage)
RADIATOR SUPPORT - TOP 120mm, 140mm, 240mm, 280mm, 360mm, (mount radiator below the bracket & fans above the bracket for maximum compatibility)
RADIATOR SUPPORT - REAR 120mm
CLEARANCE - CPU COOLER 171mm
CLEARANCE - GFX 410mm/16.1", 350mm (with stabilizer), 280mm (with stabilizer + drive cage)
CLEARANCE - PSU 276mm, 160mm (drive cage rear position)
POWER SUPPLY SUPPORT Bottom mount, ATX PS2
DUST FILTERS Top, Front, Bottom
CABLE ROUTING 27-29mm
EAN CODE 4719512087305 (Steel), 4719512087299 (TG)
UPC CODE (Steel), (TG)
