CH-923 Multi Coin Acceptor Selector Mechanism for (3 kinds of coins)

Detail CH-923 Multi Coin Acceptor Selector Mechanism for (3 kinds of coins)

Description

CH-923 is a multi coin selector, can accept up to 3 kinds of different coins at the same time. This type of coin selector is widely used in Vending machine,Arcade Game, Message chair, and other selfmanagement system. CH-923 is mainly based on material, weight and size to identify coins. We use the most up to date algorithm to design software. Therefore, CH-923 is very stable and accurate even when environment changes such as temperature, and humidity etc In order to increase the accuracy, we suggest different version of coins use different channel to set up.


Features

(1)Capable of accepting all worldwide Coins and Tokens.

(2)Intelligent CPU software control, and high accuracy .

(3)Self-programming without PC.

(4)Accept 1~3 different kinds of coins at the same time.

(5)Free to set up pulses' output.

(6)Prevent not only electric shock but also electromagnetic interference.

(7)Automatic self-test for problems.

Specifications



User Guide

The Process of Setup for Parameters

(1)Press the "Add" and "minus" buttons at the same time for about three seconds,then the letter "A" will appear from the LED display.

(2)Press the "setup" button once, and the letter "E" will appear. Next,us the buttons to choose how many kinds of coins you would like to use; then press the"setup" button again to finish.

(3)The letter "H" will appear after pressing the button. Use the "Add" and "minus"buttons to choose how many samples you would like to inse
