CEILING Speaker JBL 8128 8 inch ORIGINAL

Detail CEILING Speaker JBL 8128 8 inch ORIGINAL

Home/ Products/ Installed Sound/ 8100 Series/ 8128
8128
8-inch, Full-range,
In-Ceiling Loudspeaker

OVERVIEWFEATURESSPECS
8-inch, Full-range, In-Ceiling Loudspeaker
The 8128 is a 8-inch, full-range, cost-effective loudspeaker for commercial applications. The 8128 features high-fidelity performance in an easy to install package. The systems high sensitivity drivers deliver maximum sound levels using minimal amplifier power. With its contemporary grill design, 70V/100V taps and an open-back design, the 8100 series brings elegance and performance to basic commercial sound systems, or any application not requiring a back can for installation.

FEATURES

Clear, High-Fidelity Performance
Dog-ears for easy Blind Mount Installations
High Sensitivity (97 db, 1W, 1m) for Maximum Power Efficiency
6W Transformer for use of 70V / 100V Distributed Lines

SPECIFICATIONS
^
Component 8 in (200 mm), Full-range Driver
Frequency Range 50 Hz 16 kHz
Sensitivity 97 dB (1 kHz 8 kHz), 1W, 1M
Coverage 90 conical
70V/100V Taps 6W, 3W, 1.5W (0.75W at 70V only)
Termination Bare wires
Dimensions
(Diameter x Depth) 11.3 in (287mm) x 4.1in (105mm)
