Camera Image Sensor 2.0 megapixel progressive scan CMOS Max. Resolution 1920 (H) ×1080 (V) Min. Illumination 0.005 Lux@(F1.2, AGC ON), 0 Lux with IR Shutter Time PAL: 1/25 s to 1/50, 000 s,NTSC: 1/30 s to 1/50, 000 s Day & Night IR cut filter Angle Adjustment Pan: 0° to 360°, Tilt: 0° to 75°, Rotation: 0° to 360° Signal System PAL/NTSC Lens Lens Type 2.8 mm, 3.6 mm, 6 mm Focal Length & FOV 106° (2.8 mm), 82° (3.6 mm), 51° (6 mm) Lens Mount M12 Image Image Parameters Switch STD/HIGH-SAT Image Settings Brightness, Sharpness, 3D DNR, Mirror, Smart IR Frame Rate PAL: 1080p@25fps,NTSC: 1080p@30fps Day/Night Mode Auto/Color/BW (Black and White) Wide Dynamic Range (WDR) ≥ 120 dB Image Enhancement BLC, HLC Noise Reduction Level 1 to 9 AGC High/Medium/Low Interface Video Output Switchable TVI/AHD/CVI/CVBS General Material Metal Dimension 89.47 mm × 68.2 mm (3.52" × 2.68") Approx. 240 g (0.53 lb.) Operating Condition -40 °C to 60 °C (-40 °F to 140 °F), Humidity: 90% or less (non-condensation) Language English Power Supply 12 VDC ±25%,*You are recommended to use one power adapter to supply the power for one camera. Consumption Max. 4.6 W IR Range Up to 30 m Approval Protection IP67
