Casing Cooler Master Masterbox MB600L V2 with ODD CASE PC ATX

Detail Casing Cooler Master Masterbox MB600L V2 with ODD CASE PC ATX

SPECIFICATIONS
Model Number MB600L2-KN5N-S00 (w/ ODD Steel)
Series MasterBox Series
Size Mid Tower
Color(s) Black
Materials Steel, Plastic, Tempered Glass
Dimensions (L x W x H) 405.5x204x455.3mm (incl. Protrusions) (MB600L2-K*NN-S00), 400x204x455.3mm (excl. Protrusions) (MB600L2-K*NN-S00), 460.5x204x455.3mm (incl. Protrusions) (MB600L2-K*5N-S00), 455x204x455.3mm (excl. Protrusions) (MB600L2-K*5N-S00)
Volume 37.15L (MB600L2-K*NN-S00) (exlc. Protrusions), 42.26L (MB600L2-K*5N-S00) (exlc. Protrusions)
Motherboard Support Mini ITX, Micro ATX, ATX
Expansion Slots 7
5.25" Drive Bays 0 (MB600L2-K*NN-S00), 1 (MB600L2-K*5N-S00)
2.5" / 3.5" Drive Bays (Combo) 2
2.5" Drive Bays 2
I/O Panel 2x USB 3.2 Gen 1 Type-A, 1x 3.5mm Headset Jack (Audio+Mic)
Pre-installed Fans - Top N/A
Pre-installed Fans - Front N/A
Pre-installed Fans - Rear 1x 120mm
Fan Support - Top 2x 120/140mm
Fan Support - Front 3x 120mm, 2x 140mm, 3x 120mm (remove ODD bracket) (MB600L2-K*5N-S00)
Fan Support - Rear 1x 120mm
Radiator Support - Top 120mm, 240mm, (RAM height limit 32mm; install RAM first, then install radiator)
Radiator Support - Front 120mm, 140mm, 240mm, 280mm, 360mm (remove & reinstall ODD bracket to mount 360mm radiator (MB600L2-K*5N-S00)
Radiator Support - Rear 120mm
Clearance - CPU Cooler 161mm
Clearance - PSU 160mm (MB600L2-K*NN-S00), 180mm (MB600L2-K*5N-S00)
Clearance - GFX 350mm (w/o front fans & radiator) (MB600L2-K*NN-S00), 400mm (w/o front fans & radiator) (MB600L2-K*5N-S00)
Cable Routing 18.5mm
Dust Filters Front, Top, Bottom
Power Supply Support Bottom Mount, ATX
