CASING CHS MasterBox NR200P

Detail CASING CHS MasterBox NR200P

MODEL NUMBER
MCB-NR200P-KGNN-S00, MCB-NR200P-WGNN-S00
SERIES
MasterBox Series
SIZE
Mini ITX
AVAILABLE COLOR(S)
Black, White
MATERIALS
Steel, Plastic, Mesh, Tempered Glass
DIMENSIONS (L X W X H)
376 x 185 x 292mm incl. Protrusions, 360 x 185 x 274mm excl. Protrusions
VOLUME (EXLC. PROTRUSIONS)
18.25L
MOTHERBOARD SUPPORT
Mini DTX, Mini ITX, Max MB size: 244 x 226mm (L x H)
EXPANSION SLOTS
3
5.25" DRIVE BAYS
0
3.5" DRIVE BAYS
1 (Max. 2)
2.5" / 3.5" DRIVE BAYS (COMBO)
1
2.5" DRIVE BAYS
2 (Max. 3)
I/O PANEL
2x USB 3.2 Gen 1 Type-A, 1x 3.5mm Headset Jack (Audio+Mic)
PRE-INSTALLED FANS - TOP
2x 120mm 650-1800RPM PWM (SickleFlow)
PRE-INSTALLED FANS - FRONT
N/A
PRE-INSTALLED FANS - REAR
N/A
PRE-INSTALLED FANS - BOTTOM
N/A
FAN SUPPORT - TOP
2x 120mm
FAN SUPPORT - REAR
1x 92mm
FAN SUPPORT - BOTTOM
2x 120mm (recommended slim fans for GPUs wider than 2.5 PCI slots)
FAN SUPPORT - SIDE
2x 120/140mm
RADIATOR SUPPORT - TOP
N/A
RADIATOR SUPPORT - REAR
92mm (not compatible with vertical GPU installation)
RADIATOR SUPPORT - BOTTOM
120mm, 240mm, (recommended for custom loops only)
RADIATOR SUPPORT - SIDE
120mm, 140mm, 240mm, 280mm, (not compatible with vertical GPU installation)
CLEARANCE - CPU COOLER
76mm (GPU in vertical position), 153mm (tempered glass side panel), 155mm (vented steel side panel)
CLEARANCE - PSU
130mm
CLEARANCE - GFX
L: 330mm (incl. power connector), H: 156mm (incl. power connector), W: 60mm (triple slot)
DUST FILTERS
Top, Bottom, Left side, Right side
POWER SUPPLY SUPPORT
SFX, SFX-L
WARRANTY
2 years
EAN CODE
4719512106761 (MCB-NR200P-KGNN-S00), 4719512106778 (MCB-NR200P-WGNN-S00)
UPC CODE
884102079078 (MCB-NR200P-KGNN-S00), 884102079085 (MCB-NR200P-WGNN-S00)
WEIGHT
5.1 kg
ACCESSORIES
1x PCIe 3.0 x16 riser cable
NOTE
Single slot water-cooler GPUs or vertically mounted GPUs are recommended when using bottom radiator position, This product is only compatible for devices that support the PCI-E 3.0 specification. If you use this product with a motherboard that supports PCI-E 4.0, please enter into BIOS option and select PCI-E 3.0 before installation.
