Cambium PTP550e Connectorized |PTP 550 Connectorized

Detail Cambium PTP550e Connectorized |PTP 550 Connectorized

Cambium PTP550e Connectorized

"Tanpa Video Unboxing yang Real, Kami TIDAK Menerima Komplain"

Cambium Network is excited to introduce our latest Point to Point Gigabit throughput solution based on 802.11
ac Wave 2 operating in 5 GHz wireless space, addressing the gigabit capacity needs for high speed backhaul
solutions in mid range and long range applications.

MODEL PTP 550E Connectorized
RF BANDS Wide-band operation 4.9 to 6.2 GHz (entire frequency range)
CHANNEL SIZES Dual independent channels, each channel configurable as 10, 20, 40
& 80 MHz
SPECTRAL EFFICIENCY 8.5 bps/Hz maximum
CHANNEL SELECTION Fixed frequency or Dynamic Channel Selection (DCS)
MAXIMUM TRANSMIT POWER Up to 26 dBm
SYSTEM GAIN Up to 173 dB with Integrated Antenna
MODULATION MCS 0 to MCS 9 (256 QAM)
DUPLEX SCHEME Time Division Duplex (TDD)
Multiple transmit/receive duty cycles
ANTENNA Integrated Flat panel: 23 dBi
Connectorized: Single- and dual-polarity antennas through 2 x Ntype connectors
RANGE Up to 122 miles (200 km)
UL/DL Ratio supported 50:50 , 70:30 and 75:25
SECURITY 128-bit AES Encryption
Factory mode recovery
ETHERNET BRIDGING
LATENCY 4-5 ms one direction
PACKET CLASSIFICATION Layer 2 and Layer 3 IEEE 802.1p, Ethernet priority,VLAN
QUALITY OF SERVICE 3 Level of QoS
MAX PACKET SIZE 1700 Bytes
TDD Sync Supports CMM5 and cnPulse
FLEXIBLE I/O 1 Gigabit Port: Data + PoE power input
1 SFP port (single-mode fiber, multi-mode fiber, and copper Gigabit
Ethernet options available)
MANAGEMENT
NETWORK MANAGEMENT In-band management and Out Band Management
SYSTEM MANAGEMENT IPv6/IPv4 dual-stack management support
SNMPv2 and SNMPv3, https, WPA-PSK2
Online spectrum analyzer (no impact on payload traffic)
cnMaestro supported
INSTALLATION Built-in e-alignment using GUI on radio

Gambar produk
