Detail Cambium ePMP Force 400C 5 GHz Connectorized Radio|ePMP F400C

Cambium ePMP Force 400C 5 GHz Connectorized

"Tanpa Video Unboxing yang Real, Kami TIDAK Menerima Komplain"

SKU:9000000206

Industry first Point-to-Point
solution based on 802.11ax
delivering up to Gbps capacity
• High-Capacity Enterprise Access
• Low-Cost WISP Backhaul
• Wi-Fi hotspot backhaul
• GPON last mile
For even longer range applications, the Force 400C is a
connectorized option with two RP-SMA RF interfaces for use with
larger parabolic dishes or horn antennas.
Spectrum
Force 400C
Channel Width MHz 20 | 40 | 80
Proprietary Physical Layer 802.11ax, 2x2 MIMO/OFDM
Channel
Spacing Configurable in 5 MHz increments
Frequency Range Wide Band Operation 4910 - 6135 MHz
(Note: Country dependent based on local regulations. Support of 5870 to 6135 coming in a future
upgrade.)
MAC Layer
(Media Access Control) Cambium Proprietary
Ethernet Interface 100/1000 BaseT, Compatible with Cambium PoE & Standard PoE pinouts; 10 Gigabit SFP cage for optional SFP modules
Protocols
Used IPv4/IPv6 (Dual Management Stack), UDP, TCP, ICMP, SNMPv2c, NTP, STP, IGMP, SSH
Network Management IPv4/IPv6, HTTPs, SNMPv2c, SSH, Cambium Networks CnMaestro™
VLAN 802.1Q with 802.1p priority
Performance
Force 400C / Force 425
ARQ Yes
Maximum Capacity 1 Gbps
Latency < 5 ms
Nominal Receive Sensitivity
(w/FEC) @20 MHz Channel
MCS 0 = -93 dBm to MCS 11 (1024 QAM-5/6) = -63 dBm (per chain)
Nominal Receive Sensitivity
(w/FEC) @40 MHz Channel
MCS 0 = -90 dBm to MCS 11 (1024 QAM-5/6) = -60 dBm (per chain)
Nominal Receive Sensitivity
(w/FEC) @80 MHz Channel
MCS 0 = -87 dBm to MCS 11 (1024 QAM-5/6) = -57 dBm (per chain)
Modulation Levels (Adaptive)
MCS 0 (BPSK) to MCS 11 (1024 QAM-5/6)
Transmit Power Range +3 to +28 dBm (combined, to regional EIRP limit) (1 dB interval)
Physical
Force 400C
Connectors 1 x RJ-45, 1 x SFP, 2 x RP-SMA
Surge Supression* 1 Joule Integrated
Environmental IP67
Temperature -30°C to 65°C (-22°F to 149°F)
Wind Survival 200 km/h
