Detail BUZZER PASSIVE BUSER PASIF SPEAKER ARDUINO DC 3V 5V 12V 16 OHM 12095

BUZZER PASSIVE BUSER PASIF SPEAKER ARDUINO DC 3V 5V 12V 16 OHM 12095

PASSIVE BUZZER TIDAK DAPAT MENGHASILKAN BUNYI SENDIRI PERLU TAMBAHAN SIGNAL OSCILLATOR SEHINGGA BUNYI DIHASILKAN DAPAT DIATUR SESUAI FREKUENSI INPUT

SPESIFIKASI
TIPE - 12095
JENIS - PASSIVE BUZZER
OPERATING VOLTAGE - DC 3V / 5V / 12V
RESISTANCE - 16 OHM
SUARA - SESUAI FREKUENSI INPUT
SOUND OUTPUT -≥ 95 dB at 12 VOLT DC / 10 CM
RATED CURRENT - ≤ 12 mA at 12 VOLT DC
RESONANT FREQUENCY - 3000 ± 500 Hz
OPERATING TEMPERATURE - ﹣20℃~ +60℃
STORAGE TEMPERATURE - ﹣30℃~ +70℃

UKURAN
BODI
- DIAMETER - 12 MM
- TINGGI - 8 MM
- TINGGI KAKI - 1 MM
BERAT BERSIH - 2 GRAM

HARGA JUAL UNTUK PEMBELIAN 1 PCS
