Btsg Modul Konverter Power Step Up Step Down Dc-Dc Display Digital

Detail Btsg Modul Konverter Power Step Up Step Down Dc-Dc Display Digital

#Digital #Display #DC-DC #Step #Up #Step #Down #Boost #Board #Converter #Power #Module
Digital Display DC-DC Step Up Step Down Boost Board Converter Power Module
100% brand new and high quality
100% brand new and high quality
LM2577S + LM2596S dual chip modules, DC-DC step up step down module with wide voltage design, suitable for solar panel and other high fluctuation external input power supply
Appearance Size: Approx. 6.6 x 4.7 x 1.4cm / 2.6 x 1.85 x 0.55"
Step-up Mode: Input 3.5-28V, output: 1.25-26V
Output voltage is irrelevant to input voltage (input 3.5-28V with arbitrary value, output 1.25-26V with arbitrary value)
Step-down Mode: Input / Output current (max.): 3A, rated input/output: 1A (Please add cooling fin when working in big current)
This step-up step-down module with voltage display screen, you can see the input and output voltage
Voltage regulating mode: (Step-up) Potentiometer rotates in clockwise, (Step-down) Potentiometer rotates in anticlockwise
Note: Because of lower switching frequency and input high current, it is normal to use if it has some noise
Quantity: 1pc
