Bomac R Series Gasoline or LPG -RG(P)30A

Perlengkapan Rumah > Renovasi Rumah > Tangga > Bomac R Series Gasoline or LPG -RG(P)30A
Tersedia
Periksa harganya...
Lihat tempat menjual
Toko:PT. Indotara PersadaLihat semua produk Perlengkapan Rumah oleh PT. Indotara Persada
  • Pengiriman Ekspres
  • Barang yang diperiksa
  • Bayar di tempat berlaku
  • Kualitas, Prestise
  • Pengembalian produk
  • Dukung pembuatan faktur
DeskripsiSpesifikasi

Detail Bomac R Series Gasoline or LPG -RG(P)30A

Setiap hari buka termasuk hari minggu/libur, silahkan di pesan barangnya dan kami akan mengirimkan barang pesanan anda secepat mungkin.

Mohon Tanyakan Stock terlebih dahulu sebelum Melakukan Order !!
Untuk menghindari Penolakan Order.

Model : RG(P)30A
Power type :Gasoline or LPG
Rated capacity : 3000 kg
Load center : 500 mm
Driving mode : Site on type
SIZE
Overall max. lifting height (with backrest) : 4262 mm
Max.Lifting height : -
Height mast retracted (upright) : 2070mm
Free lift height : 168 mm
Backrest height (from upper faceof forks) : 1227mm
Overhead guard clearance (from face of seat) : 1000 mm
Overall height (overhead guard) : 2190 mm
Overall length (without forks) : 3752/2682mm
Font overhang : 479 mm
Rear overhang : 495 mm
Wheel base : 1700 mm
Coupler height : 310 mm
Min. grond clearance under mast : 135 mm
Overall width : 1225 mm
Lateral fork adusment (Outside of fork) : 1060/250 mm
Tread (front) : 1000/970 mm
Inside turning radius : 2400 mm
Outside turning radius : 200 mm
Min. intersecting aisle : 2380 mm
Tilting angles (forward/backward) : 6°/12°
Fork size : 1070x122x45 mm
PERFOMANCE
Max.Traveling speeds (laden/unladen) : 19/20 km/h
Lifting speeds (laden/unladen) : 450/500 mm/s
Lowring speeds (laden/unladen) : 450/500 mm/s
Max. Draw-bar pll (laden/unladen) : 15/9.8 kN
Max Negotiable gradient (laden/unladen) : 19/16.9 %
WEIGHT
Service mass : 4300 kg
Load wheel. laden (front/rear) : 6543/727 kg
Load wheel. Unladen (front/rear) : 1708/2562 kg
TYRES
Wheel (front/rear) X=Driving wheel : 2x/2
Tyre (front/rear) : pneumatic tyre
Tyre size (front/rear) : 28X9-15-12PR/6.50-10-10PR
Service brake : Hydraulic-Foot Pedal
Paking brake : Mechanical-Hand Lever
DRIVE AND TRANSMISSION CONTROL DEVICE
Battery voltage/capacity : 12/80 V/Ah
Internal combustion engine model : NISSAN K25

Harga asli dan marketplace kemungkinan berbeda!!

# Harga diatas sudah termasuk PPn
# Kami akan menerbitkan faktur pajak setelah transaksi
