[birth] 5Pcs duplex 223p 60pf/140pf 2.1mm hole shaft radio variable capacitor [ID]

Perlengkapan Rumah > Perkakas > Perkakas Lainnya > [birth] 5Pcs duplex 223p 60pf/140pf 2.1mm hole shaft radio variable capacitor [ID]
Tersedia
Periksa harganya...
Lihat tempat menjual
Toko:brightnessdecorate.idLihat semua produk Perlengkapan Rumah oleh brightnessdecorate.id
  • Pengiriman Ekspres
  • Barang yang diperiksa
  • Bayar di tempat berlaku
  • Kualitas, Prestise
  • Pengembalian produk
  • Dukung pembuatan faktur
DeskripsiSpesifikasi

Detail [birth] 5Pcs duplex 223p 60pf/140pf 2.1mm hole shaft radio variable capacitor [ID]

Parameters:
1. The effective Angle: 96% - 99% (180 degree qua 100%)
2. Electric capacity: 60 pf / 140 pf
3. The loss tangent value: 20x10-4
4. The insulation resistance: 500Mohm
5. Withstand voltage: 100VDC
6. Dynamic contact resistance: 20Mohm
7. Rotational torque: 5 - 25 mN.m
Fit for:Radio
Hole Diameter: 2.1mm
Pin Spacing: 6 mm
Total Size(Pin Excepted):21 x 21 x 14.5mm
Material:Plastic, Metal
Color: Clear, White, Gold Tone, Silver Tone
Weight:5.7g/1pcs
Package Content:
5pcs x Variable Capacitor
