Bionet Cardio 2000 Alat ECG 12 Chanel + Hasil Presentasi

Detail Bionet Cardio 2000 Alat ECG 12 Chanel + Hasil Presentasi

ECG 12 channel interpretive, resting ECG, A4 size print out, with one touch operation (monitoring and recording mode)
Golden Standart 12 Channel Pemeriksaan ECG

ECG Leads Simultaneous 12 Leads Resting ECG
Recording Channel 3CH+1RHY, 6CH+1RHY, 12CH,
1CH Long Time (1min)
Gain 5, 10, 20, Auto (I~aVF: 10, V1~V6: 5) mm/mV
Printing Speed 12.5, 25, 50 mm/sec
Sampling Rate Analysis Sampling Rate – 500sample/sec
Digital Sampling Rate - 8,000sample/sec
Filters AC (50/60Hz, -20dB or better),
Muscle (25~35Hz, -3dB or better),
Base Line Drift (off, 0.05, 0.1, 0.2Hz, -3dB or better),
Low Pass Filter(off, 40Hz, 100Hz, 150Hz)
Display
2 x 16 Char LCD Display
Gain, Speed, Filter Status, HR, Printing Form, Rhythm Lead
User Interface Short Key
Printer Resolution Thermal Print Head, Roll Paper
Report Paper
• Width: A4/Letter – 215mm (8.5”)
• Length: A4 – 297mm (11.7”)
Letter – 279mm (11”)
Resolution: 8dot/mm (0.125mm pitch)
Patient data ID, Name, Age, Gender, Height, Weight
Basic Measurement Heart rate(30~300bpm, ±3bpm), PR/RR int., QRS dur., QT/QTc int., P-R-T axis, SV1/RV5/R+S amp.
Electrical Internal noise: 20uV(p-p)max
Input impedance: ≥ 50MΩ
Input voltage range: ±5mV
CMRR: > 105dB
DC offset voltage: ≥ ±400mV
Patient leakage current: < 10uA
Frequency response: 0.05 ~ 150 with in –3dB
Isolated , defibrillation and ESU protected
Line Power Input: 100- 240Vac, 1.5-0.75A, 50-60Hz
Output: 15Vdc, 4.2A
Battery type
Replaceable and Rechargeable, Lithium ion, 11.1V, 2600mA
Battery Capacity 6 hours of normal use or print 200 ECG pages(12 channel format at 25mm/s and 10mm/mV)
Battery recharge to full capacity in 3hours.
Communication LAN
Safety Conformity Class I, Type CF Defibrillation-proof applied Part.
Environmental Operation Ambient Temperature: 10~40℃
Relative Humidity: 30~85%RH
Atmospheric Pressure: 70~106KPa
Environmental Storge/Ship Ambient Temperature: -20~60℃
Relative Humidity: 10~95%RH
Atmospheric Pressure: 50~106KPa
Dimensions 300(W) x 290(H) 95(H)mm, Approx. 3.0kg (Main Body)
Standard Accessory Patient Cable (1 EA), Limbs Electrodes (1 SET),
Chest Electrodes (1 SET), ECG Paper (1 EA),
Power Cord (1 EA)
Options Rechargeable Battery (1 EA),
Cart(1 EA), Hanger (1 EA

NOTE :
PASTIKAN TAMBAHKAN EXTRA PACKING.
Satu Set Sudah termasuk kabel dan accesoris lain + garansi

NOMOR IZIN EDAR: AKL 20502014005
Untuk pengajuan komplain wajib menyertakan video.
