be quiet! Silent Wings 4 - 120mm PWM - Garansi Resmi

Detail be quiet! Silent Wings 4 - 120mm PWM - Garansi Resmi

SILENT WINGS 4
120mm PWM
NO COMPROMISE SILENCE AND PERFORMANCE
Silent Wings 4 120mm PWM combines all features of a virtually inaudible with an extremely performant fan for the most demanding applications.

Optimized fan blades for the highest performance on heat sinks
Small tip clearance and a fan frame with funnel-shaped air outlets for extremely high air pressure
Virtually inaudible operation at regular speed
6-pole fan motor and fluid-dynamic bearing for less vibration and very smooth operations
Anti-vibration mounting with push pins and screwed installation option
Super-long lifespan of up to 300,000h
Elegant look with high-grade fan sticker in an all-black design
5-year manufacturer warranty

Mechanical specifications
Dimensions (L x W x H), (mm) 120 x 120 x 25
Bearing technology FDB
Motor technology 6-pole fan motor
Weight incl. fixed cables (kg) 0.190
Push pin fixing ✓
Screw fixing ✓
Cables / Connectors
Y-cable for lighting signal -
Lighting connector -
Connector 4-pin PWM
Cable length (mm) 500
Cable sleeve ✓

Performance / Noise
Air Flow @ 100% PWM / 12V (CFM / m3/h) 48.7 / 82.74
Air Pressure @ 100% PWM / 12V (mm H2O) 1.79
Noise level @ 100% PWM / 12V (dB(A)) 18.9
Lifespan (h / 25°C) 300,000
Electrical specifications
Rated Voltage DC (V) 12
Operating Voltage DC (V) 5 - 13.2
Current consumption (A) 0.12
Safety current (A) 0.13
Input power (W) 1.44
Rated Current LED (A) -

Accessories
3-pin to 4-pin 12V-connector -
12V to 7V adapter -
12V to 5V adapter -
Screws 4
Push pins 4
hard plastic washer -
Others Rubber & hard plastic mountings

Safety certification
Approvals CE / RoHs / RU / UKCA / TÜV / WEEE
