be quiet! DARK POWER PRO 12 1200W - Fully Modular - 80+ Titanium

Detail be quiet! DARK POWER PRO 12 1200W - Fully Modular - 80+ Titanium

DARK POWER PRO 12
1200W
CUTTING EDGE TECHNOLOGIES AND PERFORMANCE

The be quiet! Dark Power Pro 12 1200W offers 80 PLUS® Titanium efficiency and world class performance due to fully digital control and frameless fan concept.

80 PLUS Titanium efficiency (up to 94.7%)
Fully digital control (PFC, LLC, SR/12V) and full bridge topology
Patented frameless Silent Wings fan for virtually inaudible operation at ordinary load
Full mesh PSU front with redesigned funnel-shaped air inlet
Overclocking key switches between six 12V rails and one massive 12V rail
Japanese 105°C capacitors ensure highest stability and reliability
Aluminum case and modular individually sleeved cables for magnificent appearance
Ten-year manufacturer’s warranty

General data
Model Dark Power Pro 12 1200W
Continuous power (W) 1200
Peak power (W) 1300
Form factor Version 2.51
Form factor EPS 12V Version 2.92
Modular Cable management ✓
Topology Full bridge + LLC + SR + DC/DC
Wire-free design (DC-side) ✓
Voltage (Vac) 100 - 240
Frequency (Hz) 50 - 60
Input current (A) 16 / 8
PFC active
Power factor at 100% load >0.99
Compliant to Intel C6/C7 ✓
Power consumption in standby (W) <0.06
Average life time (h / 25°C) 300,000
Operating temperature up to (°C) 50

Cables / Connectors
Nvidia® SLI (RTX 3090) ready ✓
Cable management Modular
Sleeved cables Individually sleeved
Flat cables -
Cable length to mainboard (cm) 60
Cable length to first connector (cm) 50
Maximum cable length (cm) 120
All-in-one cable (SATA/PATA/FDD) ✓
No. of cables 17
ATX-Motherboard (20+4-pin) 1
P8 (CPU) 1
P4+4 (CPU) 1
P4 (CPU) -
PCI-e 6-pin (GPU) -
PCI-e 6+2-pin (GPU) 10
PATA 8
SATA 16
FDD (Floppy) 2
External fan connectors -
