Detail BC549 BC549C BC549CTA Transistor PNP Original ON Semiconductor

Deskripsi BC549 BC549C BC549CTA Transistor PNP Original ON Semiconductor
Harga 1 pcs

Manufacturer: ON Semiconductor
Product Category: Bipolar Transistors - BJT
RoHS: Details
hFE : 420 - 800
Mounting Style: Through Hole
Package/Case: TO-92-3 Kinked Lead
Transistor Polarity: NPN
Configuration: Single
Collector- Emitter Voltage VCEO Max: 30 V
Collector- Base Voltage VCBO: 30 V
Emitter- Base Voltage VEBO: 5 V
Collector-Emitter Saturation Voltage: 250 mV
Maximum DC Collector Current: 0.1 A
Pd - Power Dissipation: 500 mW
Gain Bandwidth Product fT: 300 MHz
Minimum Operating Temperature: - 65 C
Maximum Operating Temperature: + 150 C
Series: BC549
Packaging: Ammo Pack
Height: 5.33 mm
Length: 5.2 mm
Technology: Si
Width: 4.19 mm
Brand: ON Semiconductor / Fairchild
Continuous Collector Current: 0.1 A
Product Type: BJTs - Bipolar Transistors
