ATEN kabel USB TO Serial RS232 DB9

Detail ATEN kabel USB TO Serial RS232 DB9

UC232A USB-to-Serial Converter

UC232A is a USB to serial port converter. It provides PCs, notebook PCs and handheld computing devices using USB an external PnP RS232 port.

The UC232A now supports Android 3.2 and above. To download the UC232A App from the Android Play Store, use the search term "UC232A

Support the RS232 Serial interface.
Full compliance with the USB Specification.
Up to 230Kbps data transfer rate.
Works with cellular phones, PDAs, digital cameras, modems or ISDN terminal adapter.
OS Compatibility: WIN98, WIN ME, WIN 2K, WIN 2003, WIN XP, WIN Vista, WIN 7, WIN 8, LINUX and Mac OS 8.6/9/10.

Connectors
USB 1 x USB Type A Male (White)
Serial 1 x DB-9 Male (Silver)
Printer N/A

Data Transfer Rate
Up to 230 KBps

Cable Length
35cm

LEDs
Data Transfer / Handshaking (Orange)

Power Mode
Bus Powered

USB Specification
USB compliant

Environment
Operating Temp. 5-40C /td>
Storage Temp. -20-60C
Humidity 0~80% RH, Non-condensing

Physical Properties
Housing Plastic
Weight 0.06 kg
Dimensions ( L x W x H ) 6.59x3.40x1.60cm

Gambar produk
