ASUS TUF GAMING B660M PLUS WIFI D4 B660 LGA 1700 DDR4 Micro ATX

Detail ASUS TUF GAMING B660M PLUS WIFI D4 B660 LGA 1700 DDR4 Micro ATX

ASUS TUF GAMING B660M PLUS WIFI D4 B660 LGA 1700

CPU
- Intel® Socket LGA1700 for 12th Gen Intel® Core™, Pentium® Gold and Celeron® Processors

Chipset
- Intel B660

Memory
- 4 x DIMM, Max. 128GB, DDR4
5333(OC)/5000(OC)/4800(OC)/4600(OC)/4400(OC)/4266(OC)/4000(OC)/3733(OC)/3600(OC)/3466(OC)/3400(OC)/3333(OC)/3200/3000/2933/2800/2666/2400/2133 Non-ECC, Un-buffered Memory*

Graphics
- 1 x DisplayPort**
- 1 x HDMI® port***
*Graphics specifications may vary between CPU types. Please refer to www.intel.com for any updates.
** Supports max. 4K@60Hz as specified in DisplayPort 1.4.
***Supports 4K@60Hz as specified in HDMI 2.1.
**** VGA resolution support depends on processors' resolution.

Expansion Slots
- Intel® 12th Gen Processors
# 1 x PCIe 5.0 x16 slot
- Intel® B660 Chipset*
# 1 x PCIe 3.0 x16 slot (supports x4 mode)
# 1 x PCIe 4.0 x1 slot
* Supports Intel® Optane Memory H Series on PCH-attached PCIe slot.

Storage
- Supports 2 x M.2 slots and 4 x SATA 6Gb/s ports
- Total supports 2 x M.2 slots and 4 x SATA 6Gb/s ports*
- Intel® 12th Gen Processors
# M.2_1 slot (Key M), type 2242/2260/2280
## Intel® 12th Gen processors support PCIe 4.0 x4 mode.
- Intel® B660 Chipset**
# M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
# 4 x SATA 6Gb/s ports
* Intel® Rapid Storage Technology supports SATA RAID 0/1/5/10.
** Intel® Rapid Storage Technology supports Intel® Optane Memory H Series on PCH attached M.2 slots.

Ethernet
- 1 x Realtek 2.5Gb Ethernet

Form Factor
- microATX
- 24.4cm x 21.1cm

Wireless & Bluetooth
- Intel® Wi-Fi 6
- 2x2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax)
- Supports 2.4/5GHz frequency band
- Bluetooth v5.2*
*Bluetooth v5.2 function will be ready in Windows 11 or later.

Garansi Resmi 3 Tahun Asus Indonesia
