ASUS ProArt B550 Creator AMD AM4 B550 ATX Content Creator Motherboard

Detail ASUS ProArt B550 Creator AMD AM4 B550 ATX Content Creator Motherboard

#GARANSI RESMI ASUS 3TAHUN

CPU
AMD Ryzen™ 5000 Series/ 4000 G-Series/ 3000 Series Desktop Processors


Chipset
B550


Memory
AMD Ryzen™ 5000 Series/ 3000 Series Desktop Processors

DDR4
4866(O.C)/4600(O.C)/4400(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3333(O.C.)/3200/3000/2800/2666/2400/2133 MHz ECC and non-ECC, Un-buffered Memory *"
AMD RyzenTM 4000 G-Series Processors
DDR4
5100(O.C)/4800(O.C.)/4600(O.C)/4466(O.C.)/4400(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3600(O.C.)/3466(O.C.)/3200/3000/2800/2666/2400/2133 MHz ECC and non-ECC, Un-buffered Memory"
OptiMem II
Dual Channel Memory Architecture
ECC Memory (ECC mode) support varies by CPU.


Graphics
1 x HDMI™ 2.1 (4K@60Hz)
2 x Intel® Thunderbolt™ 4 ports (USB Type-C®) support DisplayPort 1.2/1.4 and Thunderbolt™ video outputs *
* Output at TBT4_E1 and TBT4_E2, the USB Type-C® ports right under RJ45 ports, each requires a USB-C to DisplayPort adapter cable. Graphics specifications may vary between CPU types.
** VGA resolution support depends on processors' or graphic cards' resolution. For more details about the video input and output settings please refer to the user manul.


Expansion Slots
2 x PCIe 4.0/3.0 x16 (x16, x8/x8)
AMD Ryzen™ 5000 Series/ 3000 Series Desktop Processors
2 x PCIe 4.0 x16 (x16 or dual x8)*
AMD RyzenTM 4000 G-Series Processor
2 x PCIe 3.0 x16 (x16 or dual x8)*
AMD B550 Chipset
1 x PCIe 3.0 x16 slot (supports x4 mode)**
2 x PCIe 3.0 x1 slots***

* Support PCIe bandwidth bifurcation for RAID on CPU function.
** PCIe 3.0 x4 will be switched from Thunderbolt™ 4 to PCIEX16_3 if the slot is populated; by then Thunderbolt™ 4 will have no output
*** These PCIe x1 slots share bandwidth with M.2_2, which runs at PCIe 3.0 x4 by default. You may go to BIOS setting to set M.2_2 to PCIe 3.0 x4 or x2 at will

Gambar produk
