Pump/Cold Plate : - VRM Fan : 40 mm, 1000 – 3000 RPM (PWM controlled) - Pump : 800 – 2000 RPM (PWM controlled) - Power Consumption : 0,5 W – 2,7 W (Pump + VRM Fan) - Cold Plate : Copper, Micro-Skived-Fins - Thermal Paste : MX-5 (0,8 g)
Fan : - Fan : 2x ARCTIC P14 PWM A-RGB – 140 mm Fan - Fan Speed : 200 – 1 900 RPM - Fan Bearing : Fluid Dynamic Bearing - Noise Level : 0.3 Sone - Voltage / Current : 0.17 A / 12 V DC - Airflow : 68.9 CFM - Static Pressure : 2 mm H2O - Connector : 4 pin Connector
RGB : - LEDs : 12 A-RGB LEDs per Fan - Connector : 3 pin 5 V-DI-Gnd - Current/Voltage : 0.4 A/ 5 V
Size & Weight : - Radiator : 317 x 138 x 38 mm - Pump (w/o tubes) : 98 mm x 78 mm x 53 mm - Tube Diameter : Outer: 12,4 mm // Inner: 6,0 mm - Tube Length : 450 mm - Weight : 1600 g (Fan, Radiator, Pump, Tubes)
