ARAKI SINGLE SCREW AIR COMPRESSOR GTR18.5A 13BAR

Detail ARAKI SINGLE SCREW AIR COMPRESSOR GTR18.5A 13BAR

Setiap hari buka termasuk hari minggu/libur, silahkan di pesan barangnya dan kami akan mengirimkan barang pesanan anda secepat mungkin

ARAKI Heavy Duty Screw Compressor
Type : GTR18.5A
Power : 18.5KW/25HP
Voltage (V) : 3Ph/380V/50Hz
Pressure : 13 Bar (1.3 Mpa)
Air Delivery : 81.3 Cfm (2.3 m3/min)
Motor Speed : 2970 Rpm
Air Supply Oil Content : ≤ 3 PPM
Pipe Size (Ø mm) : 1”
Transmission Model : Coupling Transmission (No Vanbelt)
Lubrication System : High Pressure Filtered Oil
Oil Cooling Sistem : Radiator + Cooling Fan
Cooling Fan Power : 550W
Controller : Smart Microcontroller + LCD Display
Safety Valve : Ready
Startup Model : Y - Δ startup
Air Supply Temperature : ≤ Ambient Temperature +15℃
Noise : 60 dB (From 7m)
Dimension (LxWxH)mm : (1300x800x1115) mm
Weight (Kg) : 750 Kg

Feature :
- Programmable Logic Controller ( PLC ) by MAM
- Oil filter by MANN Filter , Germany
- Electrical control by Schneider , France
- Magnetic Valve & Pressure Controller by Burkert,Germany
- Unloading Valve by Hoerbiger , Austria
- 3 Years Warranty

Dapatkan produk-produk berkualitas tinggi dengan harga yang ekonomis.
Hati-hati barang tiruan, Produk yang asli hanya ada di PT. Indotara Persada.
