APC SRT1000XLI Smart UPS Online 1000VA 1000Watt

Detail APC SRT1000XLI Smart UPS Online 1000VA 1000Watt

APC SRT1000XLI Smart UPS Online 1000VA 1000Watt
Output
Output Power Capacity 1000 Watts / 1000 VA
Max Configurable Power (Watts) 1000 Watts / 1000 VA
Nominal Output Voltage 230V
Output Voltage Distortion Less than 2%
Output Frequency (sync to mains) 50/60Hz +/- 3 Hz
Other Output Voltages 220, 240V
Crest Factor 3 : 1
Crest Factor Double Conversion Online
Waveform Type Sine wave
Output Connections (6) IEC 320 C13 (Battery Backup)
Disclaimer: This documentation is not intended as a substitute for and is not to be used for determining suitability or reliability of these products for specific user applications
Jan 15, 2020
1
Bypass Built-in Bypass
Input
Nominal Input Voltage 230V
Input Frequency 40 - 70 Hz (auto sensing)
Input Connections IEC-320 C14
Cord Length 1.83 meters
Input voltage range for main
operations
50-150 (40% Load) V , 80 - 150 V
Other Input Voltages 220 , 240
Batteries & Runtime
Battery Type Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
Included Battery Modules 1
Typical recharge time 3 hour(s)
Replacement Battery APCRBC155
RBC Quantity 1
Nominal Battery Voltage 48V
Communications & Management
Interface Port(s) RJ-45 Serial , Smart-Slot , USB
Available SmartSlot™ Interface
Quantity
1
Control panel Multi-function LCD status and control console
Audible Alarm Audible and visible alarms prioritized by severity
Emergency Power Off (EPO) Yes
Surge Protection and Filtering
Surge energy rating 432 Joules
Physical
Maximum Height 432.0 mm
Maximum Width 85.0 mm
Maximum Depth 505.0 mm
Net Weight 20.5 kg
Shipping Weight 29.6 kg
Shipping Height 246.0 mm
Shipping Width 594.0 mm
Shipping Depth 749.0 mm
Color Black
