AMD Ryzen™ 5 7600X Desktop Processor | Ryzen 5 7000 Series 6Core AM5

Detail AMD Ryzen™ 5 7600X Desktop Processor | Ryzen 5 7000 Series 6Core AM5

𝗦𝗽𝗲𝗰𝗶𝗳𝗶𝗰𝗮𝘁𝗶𝗼𝗻𝘀 :

Platform
- Desktop

Market Segment
- Enthusiast Desktop

Product Family
- AMD Ryzen™ Processors

Product Line
- AMD Ryzen™ 5 Desktop Processors

AMD PRO Technologies
- No

Consumer Use
- Yes

Regional Availability
- Global

Former Codename
- "Raphael AM5"

Architecture
- "Zen 4"

# of CPU Cores
- 6

Multithreading (SMT)
- Yes

# of Threads
- 12

Max. Boost Clock
- Up to 5.3GHz

Base Clock
- 4.7GHz

L1 Cache
- 384KB

L2 Cache
- 6MB

L3 Cache
- 32MB

Default TDP
- 105W

Processor Technology for CPU Cores
- TSMC 5nm FinFET

Processor Technology for I/O Die
- TSMC 6nm FinFET

CPU Compute Die (CCD) Size
- 71mm²

I/O Die (IOD) Size
- 122mm²

Package Die Count
- 2

Unlocked for Overclocking
- Yes

AMD EXPO™ Memory Overclocking Technology
- Yes

Precision Boost Overdrive
- Yes

Curve Optimizer Voltage Offsets
- Yes

AMD Ryzen™ Master Support
- Yes

CPU Socket
- AM5

Supporting Chipsets
- X670E
- X670
- B650E
- B650

CPU Boost Technology
- Precision Boost 2

Instruction Set
- x86-64

Supported Extensions
- AES, AMD-V, AVX, AVX2, AVX512, FMA3, MMX(+), SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64

Thermal Solution (PIB)
- Not included

Max. Operating Temperature (Tjmax)
- 95°C

Launch Date
- 9/27/2022

NVMe Support
- Boot, RAID0, RAID1, RAID10

Memory Channels
- 2

Max. Memory
- 128GB

System Memory Subtype
- UDIMM

Max Memory Speed
- 1x1R 5200 MT/s

ECC Support
-Yes (Requires mobo support)

Integrated Graphics
-Yes

Graphics Model
- AMD Radeon™ Graphics

Graphics Core Count
- 2

Graphics Frequency
- 2200 MHz

GPU Base
- 400 MHz
