AFOX H81 MA MOTHERBOARD INTEL LGA 1150 HASWELL

Detail AFOX H81 MA MOTHERBOARD INTEL LGA 1150 HASWELL

Processor :
-Support Intel Core i7/i5/i3/Pentium/ Celeron processors in the LGA1150 package.
-Support Intel 4th generation multi-core processors
Chipset : Intel H81
On-Board graphics : Integrated Graphics Processor
Memory Support : Dual Channel DDR3 1333/1600MHz Memory, up to 16GB
Dimm : 2 x Memory Slots (Max. up to 8GB each)
LAN : Realtek RTL8105E 100M / RTL8111E 1000 Mbps on board
Audio : Chip integrated by Realtek ALC662 on board, Supports 6-channel audio-out
Slot : 1 x PCI Express x16 Slot
Storage : 4 x SATA II port
Internal :
-I/O Ports 1 x 24-pin ATX Power Connetor
-1 x 4-pin ATX 12V Power Connetor
-1 x USB 2.0 connector support additional 2 USB 2.0 ports
-1 x Front panel audio connector
-1 x System Panel connector
Back I/O Ports :
-1 x USB 2.0 keyboard port
-1 x USB 2.0 mouse port
-1 x VGA
-1 x HDMI
-2 x USB 2.0
-2 x USB 3.0
-1 x LAN jack
-3 x Audio jack
BIOS : AMI BIOS
Form Factor : Micro ATX - 190*170 mm

Dual-Channel DDR3 1333 / 1600 support
This motherboard supports DDR3 memory that features data transfer rates of 1600
(O.C.)/1333/1066 MHz providing great performance for 3D graphics and other
memory-demanding applications

SATA 3Gb/s
This motherboard supports hard drives based on the Serial ATA (SATA) 3Gb/s
storage specifications, delivering enhanced scalability and doubling the bus
bandwidth for high-speed data saving and retrieval.

Gigabit LAN
The on-board LAN controller is a highly integrated GbLAN controller. It is
enhanced with an ACPI management function to provide efficient power management
for advanced operating systems.
