AFOX H110D4-MA2-V2 NVME LGA1151

Detail AFOX H110D4-MA2-V2 NVME LGA1151

HARAP MEMASTIKAN STOK TERLEBIH DAHULU SEBELUM MELAKUKAN TRANSAKSI

Untuk pengiriman ke luar kota, Wajib tambahkan packing untuk keamanan pengiriman dengan link berikut ini,
untuk dus :
https://shopee.co.id/PACKING-KARDUS-i.75752086.11869241633?sp_atk=ccda4f9e-a299-446e-adbd-275a77480277
Buble wrap :
https://shopee.co.id/PACKING-BUBBLE-WARP-BUNGKUS-BARANG-ANTI-SHOCK-i.75752086.13345605923?sp_atk=8ddf707c-bf89-41ab-93ab-fe05fadd109a


Platform
INTEL Socket 1151

Model Name
IH110D4-MA2-V2

Chipset
Intel® H110

CPU Supports
Intel Core™ i7 / Core™ i5 / Core™ i3 / Pentium® / Celeron® Processors
Supports Intel 6th, 7th, 8th and 9th Generation (CPU up to 95 watts)

FSB
2133 / 2400 / 2666 MHz

Memory
Dual Channel DDR4 2133 / 2400 / 2666(O.C.) MHz

Dimm
2 x Memory Slots (Max. capacity of system memory 32GB)

Onboard Graphics
Integrated Graphics Processor-Intel® HD Graphics support

PCI/PCI-E Slots
1 x PCI Express x16 3.0 slot

SATA
4 x SATA3, 1 x M.2 (PCIe NVMe Gen3 x4 )

IDE
N/A

Audio
Realtek 662 on board, Supports 6-channel audio-out

LAN
Realtek RTL8111 1000Mbps Ethernet on board

Back Panel I/Os
1 x HDMI Port
1 x D-Sub (VGA) Port
2 x USB 3.0 Ports
4 x USB 2.0 Ports
1 x RJ-45 LAN Port with LED
3 x HD Audio Jacks (Line in / Front Speaker / Microphone)

ON-Board Pinheaders/Connectors
1 x USB 2.0 pinheader (supports additional 2 USB 2.0s), 1 x USB 3.0 pinheader (supports additional 2 USB 3.0s)
1 x Front Panel Audio pinheader
1 x LPC DEBUG

BIOS
UEFI BIOS

Form Factor
Micro-ATX (17*19cm)

Mounting
4 mounting holes

Accessories
1 x SATA II cable
1 x I/O Rear Panel
1 x User Manual
1 x Driver CD
