ACASIS 4K HDMI Video Capture Card USB Type C for Live Streaming

Detail ACASIS 4K HDMI Video Capture Card USB Type C for Live Streaming

Brand：ACASIS
Input interface: HDMI input with loop out
Support resolution: 4096*2160p and 1920*1080p standard resolution
HDMI input format: comply with HDMI3.1 standard. Support 36bit DeepColor After-sales service: Provide free technical support + 1 year warranty
Host interface: "USB3.0, *300-350MB/s transmission bandwidth
USB2.0, *40MB/s transmission bandwidth"
Input interface: 1 HDMI interface
HDMI video input: HDMI video input 1 channel 1080P/60Hz HDMI HD
HDMI input format: Comply with HDMI 1.4a standard, support 1080p/60Hz 8-bit, (RGB, YUV)
HDMI output interface: 1 HDMI output port, 1920x1080 frame rate: 60 fps 4K-30FPS
USB output format: 640x480-1920x1080. Frame rate: 25/30/60 fps
Audio input interface: LINE IN3.5MM audio input
Video sampling rate: HDMI: 165MHz
Audio and video capture: Comply with UVC (USB video class), UAC (USB audio class) specifications
Output color space: YUY2, MJPEG.
Color space conversion: hardware color space conversion
Screen zoom: hardware zoom
Operating system support: "supports x86 and x64 versions of the following operating systems:
Windows 7
Windows Server 2008 R2
Windows 10
Linux (Kernel version 2.6.38 and above)
OS X (10.8 and above)"
Adobe Flash Media Live Encoder (Windows, OS X)
Real Producer Plus (Windows)
VLC (Windows, OS X, Linux)
QuickTime Broadcaster (OS X)
QuickTime Player (OS X)
Wirecast (Windows, OS X)
OBS-Studio
DaumPotPlayer etc..."
Compatible development interface: "DirectShow (Windows), DirectSound (Windows),
V4L2 (Linux), ALSA (Linux)"
Onboard memory: 64MB DDR2, working frequency is 300 MHz, bit width is 16bit
Upgrade: the firmware can be upgraded
Power consumption: <= 3.5W
Operating temperature range: 0_50 degrees Celsius

Note :
Untuk HP Android pastikan support MHL
Untuk iPhone support 6s ke atas

Package Included:
1 x ACASIS HDMI Video Capture
1 x HDMI to HDMI Cable
1 x Type C to USB 2.0 Cable
1 x User Manual
