【Hadiah gratis】7018B universal Head Unit Android/iPhone Double Din 7 Inch Bluetooth Audio Car MP3 MP5 Player In Touch Screen Radio Dan Kamera Mundur Mobil LED

Detail 【Hadiah gratis】7018B universal Head Unit Android/iPhone Double Din 7 Inch Bluetooth Audio Car MP3 MP5 Player In Touch Screen Radio Dan Kamera Mundur Mobil LED

Video perkenalan produk 7018B universal Head Unit Android/iPhone Double Din 7 Inch Bluetooth Audio Car MP3 MP5 Player In Touch Screen Radio Dan Kamera Mundur Mobil LED. Sumber: Shopee.

Fitur:
💕 Radio
💕Sports membaca USB flash drive (audio/video/gambar)
💕 Fungsi aux
💕 Fungsi Bluetooth
💕 Output audio RCA dapat dihubungkan ke subwoofer
💕 Membalikkan fungsi input kamera tampilan belakang (kamera tidak termasuk)
Input Video, output video
💕 Fungsi Pembelajaran Roda Kemudi Mobil Asli
💕 Mendukung Layar Telepon Mirroring ke Radio Mobil (untuk iPhone/Android)
💕 Lampu berwarna -warni
💕USB Port pengisian daya untuk perangkat elektronik Anda
💕 （7018B/7020 not support）Temukan mobil saya melalui aplikasi gratis (hanya tersedia dengan opsi '' bt temukan radio ''). (Setelah parkir, ponsel Anda dapat mengingat lokasi parkir dan dapat menavigasi ke lokasi parkir itu nanti)

⭐⭐⭐Important notice before installation:
Yellow line (for memory wire) connected to the battery constant current positive, the machine will have memory function.
Red line pick the key to the ACC line, this line is also positive, control power switch. Black wire connected to the negative power supply.
Blue line connected lift the antenna or subwoofer REM control line, if not have do not connected, wrapped up with rubberized fabric.
The remaining eight wires(gray white green purple) are speaker line, a group of colors corresponding to a pair of speaker lines (positive and negative).
Please pay attention to check whether the original car speaker cable if contact iron (the original car speaker wire welding to the metal, or a speaker only a line thow out, called contact iron). contact iron will cause our high-power machine without sound, please test it with a multimeter before install, if contact iron, please disconnect and then install.


Spesifikasi:

OS: WinCE
Chip penguraian kode: Quanzhi C500
Ukuran layar: 7 inci
Resolusi layar: 1024*600
Ukuran panel: 178mm * 100mm/7.01*3.94"
Kedalaman: 50mm/1.97"
Interkoneksi ponsel: mendukung Android
Navigasi GPS: Tidak Didukung
Pita radio: pita tunggal FM
Chip radio: QN8035
Bahasa: Inggris, Cina, Prancis, Portugis, Spanyol
Pencerminan layar: Tidak didukung
Membalikkan input video: Dukungan
Membalikkan metode deteksi: deteksi garis ekor
Fungsi pengingat rem: Ya
Fungsi kontrol roda kemudi: Ya
Bluetooth: Dukungan
Chip penguat daya: TDA7388
Frekuensi radio: 87.5M-108M
Slot kartu memori: mendukung kartu TF
Slot kartu GPS: Tidak ada fungsi GPS
Remote control: Ya, remote control 21 tombol
Port USB: Ya
Tombol reset: ya, RST
Jenis steker: steker ISO
Terminal RCA: 2 output video, 1 input terbalik, 2 output audio, 1 input video
Input audio AUX depan: Ya
Tombol volume: Ya
Format audio yang didukung: MP3/WMA/WAV/OGG/FLAC/APE
Format video yang didukung: RM/RMVB/MP4/FLV/MKV/3GP/AVI/ASF/SWFMP1/MP2
Format gambar yang didukung: JPG

Paket termasuk:
1 X Radio Mobil
1 X Pengendali Jarak Jauh
1 X Kabel
1 X Manual
