5 Pcs Tombol Switch LP Backlit Untuk Keyboard Mekanik

Detail 5 Pcs Tombol Switch LP Backlit Untuk Keyboard Mekanik

Key benefits
Engineered and Made in Germany
CHERRY MX Low Profile RGB Red switch: Without pressure point, linear light actuation switching function with a defined force of approx. 45 cN without contact feedback
Designed for use with SMD LEDs (RGB or single colour)
More consistent lighting throughout the keycap due to optimized switch design
Option to use all 16.8 million RGB colours in high luminosity (scope of supply does not include LED)
SMD LEDs directly mounted on the circuit board for cost-efficient, fully automated production
High-precision mechanical switch with very low operating point tolerance
World exclusive CHERRY Gold Crosspoint technology
Short bounce time for high switching frequency (such as for fast typing)
Self-cleaning contacts
Switch resistant to dust and dirt
Over 50 million keystrokes with no loss of quality

Technical Data
Protection class: IP40
Operation characteristics: Low Profile, linear
Switching voltage: 12V AC/DC max.
Dielectric strength: 500V / 50Hz
Durability: > 50 million actuations
Contact configuration: Single-pole contact
Actuator travel: 3.2 ± 0.25 mm
Pretravel: 1.2 ± 0.3 mm
Initial force: 40 cN min.
Actuation force: 45 ± 15 cN
Bounce time: typically 1 ms
Minimum lead spacing: 16 mm
Lighting: SMD LED, mounted directly on the circuit board
Insulation materials: Thermoplastics
Spring: Stainless steel
Contacts: High-quality gold alloy
Storage Temperature: -40°C to 70°C
Operating Temperature: 5°C to 40°C
Humidity: Storage: average <50% max.
operation: 5% to 95% without
condensation
Package includes:5pcs/set
