4.2mm Metal Terminal for 5559 Connector Terminal Pin Molex 5559 Inner

Elektronik > Elektronik Lainnya > 4.2mm Metal Terminal for 5559 Connector Terminal Pin Molex 5559 Inner
  • Pengiriman Ekspres
  • Barang yang diperiksa
  • Bayar di tempat berlaku
  • Kualitas, Prestise
  • Pengembalian produk
  • Dukung pembuatan faktur

Detail 4.2mm Metal Terminal for 5559 Connector Terminal Pin Molex 5559 Inner

Hi #RekanEasyWare ...
- EasyWare Part#: EP001076

Catatan:
- Foto asli stok EasyWare Electronics.
- Kualitas high quality, datasheet tersedia, mangga bisa dibandingkan dengan konektor yang dijual ditempat lain dengan harga yang setara.

Spesifikasi:
- Current Rating: 9A AC, DC
- Voltage Rating: 300V AC, DC
- Temperature range: -25°C to +105°C
- Withstand voltage: 1500V AC/minute
- Applicable wire: AWG #28 to #16
- Applicable PCB thickness: 1.6 to 2mm

Kelengkapan:
- 1x 4.2mm Metal Terminal for 5559 Connector
