3G / SDI TO HDMI CONVERTER SH-003

Detail 3G / SDI TO HDMI CONVERTER SH-003

JUAL : 3G/SDI TO HDMI CONVERTER SH-003

SH-003 3G/SDI to HDMI converter adalah alat untuk konversi sinyal SD-SDI, HD-SDI and 3G-SDI untuk ditampilkan ke Layar sinyal HDMI.
Alat ini support Kecepatan transmit data hingga 2.970 Gbit/s, dengan demikian bisa meminimalkan kehilangan distorsi sinyal.
Converter ini biasa di gunakan untuk kamera video professional ukuran besar (panggul) yang ada konektor BNC / SD (seperti kamera black magic)


Features:

Operation at 2.970Gbit/s, 2.970/1.001Gbit/s, 1.485Gbit/s, 1.485/1.001Gbit/s and 270Mbits/s
Supports SMPTE 425M (Level A and Level B), SMPTE 424M, SMPTE 292M, SMPTE 259M-C
Equalized and re-clocked loop output, Integrated audio de-embedder for a maximum of 8 channel, 48 kHz audio
Conversion from SMPTE 425M level B to Level A 1080p 50/59.94/60 4:2:2 10-bit
Connect with other units to extend your signal over long distances



Specificaitons :

Input Port: 1 x BNC (SDI/HD-SDI/3G-SDI)
Output Port: 1 x HDMI
SMPTE Standard: 425M Level A & B, 424M, 292M, 259M-C
SDI Transmission Rates: 2.970 Gbit/s and 2.970/1.001 Gbit/s
In/Output Resolution: 480i, 576i, 720p@50/59.94,60 , 1080i@50/59.94/60, 1080p@23.98/24/25/29.97/30/50/59.94/60, 1080PsF@23.98/24/25/29.97/30
Weight: 160 g
Size : 96 x 55 x 25 mm


isi paket :

1 x 3G/SDI TO HDMI CONVERTER SH-003
1 x Adaptor power Supply
1 x Manual

Gambar produk
