Detail 24 In 1 Tester Usb 3.0 Pengukur Tegangan Arus Listrik Dengan Monitor Proteksi
【Friends Welcome to #OlahragaOutdoorElektronik# store , If you love our products, please clickSpecification:
Voltage range (V): DC4.000V~25.00V
Current range (A): 0.1000A~5.000A
Capacity range (mAh): 0~99999mAh
Power range (mWh): 0~99999mWh
Power range (W): 0~125W
Impedance range (Ω): 0~9999.9Ω
Temperature range (°C/°F): -30℃~89℃/-22℉~192℉
Timing range (T): 99:60:60
Low Voltage Protection (LVP): 4V~25V Default 3.9V
Voltage Overrun Protection (OVP): 4V~25V Default 25V
Current Overrun Protection (OCP): 0.1A~5A Default 3A
Over power protection (OPP): 0~125W Default 25W
Charging mode identification (mode): QC2.0, QC3.0, APPLE 2.4A/2.1 A/ 1A /0. 5 A, Android DCP, SAMSUNG (Fast charge recognition mode is for reference only, mobile phone update is fast and cannot be accurately identified.)
Refresh rate: 1.25Hz
Screen display type: 0.96 inch IPS color LCD screen
Product size: :72.12×27.00×11.50mm
product weight: 20g
Button function introduction
1.Click to switch each display interface.
2.long press the button to switch function under interface ② and ③
3.interface④⑤⑥⑦button function is as follows
a. Double-click the parameter value to increase, double-click and long press the parameter value to continue to increase;
b. The value of the three-stroke parameter is reduced, and the length of the third-level parameter continues to decrease according to the parameter value.
Overrun protection
When any one of the input voltage, current and power exceeds the system preset value, The meter will cut off the output and the interface will prompt.
Fully powered off
The starting current is >50mA. When the current falls back below 50mA, the system determines that the device is full, and the interface will prompt to complete and cut off the output.
Notice: The power-off protection function is only for the output, and the input cannot be cut off! ! !
Package Included:
1* USB 3.0 24 in 1 Tester Voltage Current Power Capacity Meter Power-off Protection
#DIYMORE # Tester #USB #Voltage #Current
