Detail 220v REX C-100 DIGITAL PID TEMPERATURE CONTROLLER C100 C 100 control
hanya dapat rex c100 saja, tanpa thermocouple*********
ouputnya RELAY
******
REX C100 TEMPERATURE CONTROLLER (REX-C100 FK02-M*EN) adalah modul controller/thermostat digital untuk mengendalikan ON offnya, pemanas (Heater), mesin penetas telur dan alat pemanas lainnya.
-- Probe Sensor Thermocouple yang compatible (K,J,S,E,R,B,N,T,PT100)
**Spesifikasi:
Model: REX-C100 Temperature Controller Kit
Measuring accuracy: 0.5% FS
Cold-end compensation tolerance: ~2C (can be modified by software in 0~50C)
Resolution: 14 bit
Sampling cycle: 0.5 Sec
Power supply: 220V AC
Indicator Process value (PV), Setting value (SV) Output, alarm and self-tuning: LED
PIN control: Self-tuning (including ON/OFF, step-type PID and continuous PID)
Relay output: contact capacity 250V AC 3A (resistive load)
Alarm function output: 1 way
Contact capacity of output: 250V AC 3A (resistive load)
Setting value (SV): identical to measuring range (PV)
Integral time (I) and Derivative time (D) : 0 ~ 3600 sec (No integral action when set to 0)
Heat-reset proportional cycle: 1 ~ 100 sec
Detective temp range: 0 to 400C
Power consumption: 10 VA
Thermocouple type: K,J,S,E,R,B,N,T,PT100
Size: 48x48x110mm
Probe Sensor Suhu Thermocouple Type K, sebagai sensor untuk mendeteksi suhu 0-400C dan banyak dipakai pada thermostat, thermometer, sensor dan berbagai pengendali suhu lainnya.
**Kelengkapan:
1pcs REX C100 Controller
1lbr User Manual
Gambar produk
